Lawn Tractor · 2002Unverified
Toro Wheel Horse GT/315-8
Toro Wheel Horse GT/315-8 — Classic 300 Series · 15 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
15 hp
Weight
283 kg
Hover a source tag to verify
Overview
ManufacturerToroReference
Garden tractorReference
Original price was $4,340 in 2007Reference
The GT 315-8 carries Toro model number 73450.Reference
Two-wheel driveReference
SteeringmanualReference
Open operator station.Reference
Engine
15HP Koher 426cc 1-cyl gasolineReference
Fuel tank8.5 LReference
Koher CommandReference
gasolineReference
1-cylinderReference
air-cooledReference
Displacement26 ciReference
Power (gross)11.2 kWReference
Starter volts12Reference
SparkplugChampion RC12YCReference
SparkplugChampion Gold 2071Reference
Sparkplug gap1.016 mmReference
Transmission
6-speed gearReference
TransmissionUni-DriveReference
TypegearReference
Gears6 forward and 2 reverseReference
Oil capacity1.9 LReference
Oil typeSAE 90 GL5Reference
Three gears (1-3) plus reverse (R) with high and low ranges.Reference
Dimensions
Wheelbase115 cmReference
Weight283 kgReference
Front tire16x6.5Reference
Rear tire23x9.5Reference
Lawn/turf front16x6.5Reference
Lawn/turf rear23x9.5Reference
Length165 cmReference
Width92 cmReference
Toro GT/315-8 attachments
36" mid-mount mower deckReference
42" mid-mount mower deckReference
48" mid-mount mower deckReference
GT/315-8 Serial Number Location
Serial number decal under the front left side of the tractor's seat.Reference
GT/315-8 Serial Numbers
2002220000001 (73450)Reference
2003230000001 (73450)Reference
2004240000001 (73450)Reference
2005250000001 (73450)Reference
2006260000001 (73450)Reference
2007270000001 (73450)Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
36" mid-mount mower deckReference
42" mid-mount mower deckReference
48" mid-mount mower deckReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
