Lawn Tractor · 2007Unverified
Toro Z4800 74812
Toro Z4800 74812 — Titan Series · 22 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
22 hp
Hover a source tag to verify
Overview
ManufacturerToroReference
Zero-turn mowerReference
Original price was $4,599 in 2008Reference
Two-wheel driveReference
Power steeringReference
open operator stationReference
Variants
Z4800Briggs engineReference
Z4800KKohler engineReference
Engine
22HP Briggs & Stratton 724cc 2-cyl gasolineReference
Fuel tank15.1 LReference
Briggs & Stratton 44K777Reference
gasolineReference
2-cylinderReference
air-cooledReference
Displacement44.2 ciReference
Bore/Stroke79 x 73 mmReference
Power (gross)16.4 kWReference
StarterelectricReference
Starter volts12Reference
Oil capacity1.9 LReference
SparkplugChampion XC12YCReference
Sparkplug gap0.762 mmReference
Transmission
hydrostaticReference
TransmissionHydro-Gear ZT-2800Reference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchelectricReference
Dimensions
Front tire10x4Reference
Rear tire20x9Reference
Lawn/turf front10x4Reference
Lawn/turf rear20x9Reference
Front axleCasterReference
Toro Z4800 attachments
48" mid-mount mower deckReference
Z4800 Serial Numbers
2007270000001Reference
2008280000001Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
48" Mower deck
Typemid-mount ToroReference
Type3-blade with manual liftReference
Cutting width121 cmReference
Cut height3 to 11 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
