The Toro Z5200K 74818 is a lawn tractor rated at 25 hp, positioning it at the more powerful end of its class. Introduced in 2008, it features a 2-cylinder petrol air-cooled engine and a two-wheel drive configuration with hydrostatic transmission. This model is designed to accommodate operations of up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
25 hp
Catalogue coverage
Variants represented
2
Richest spec table
41 rows
Recorded power
25 hp
Transmissions
hydrostatic
Production years
2008-2008
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerToroReference
Zero-turn mowerReference
Original price was $5,399 in 2008Reference
Two-wheel driveReference
Power steeringReference
open operator stationReference
Variants
Z5200Briggs engineReference
Z5200KKohler engineReference
Engine
25HP Kohler 724cc 2-cyl gasolineReference
Fuel tank15.1 LReference
Kohler SV830Reference
gasolineReference
2-cylinderReference
air-cooledReference
Displacement44.2 ciReference
Bore/Stroke83 x 67 mmReference
Power (gross)18.6 kWReference
StarterelectricReference
Starter volts12Reference
Oil capacity1.9 LReference
SparkplugChampion XC12YCReference
Sparkplug gap0.762 mmReference
Transmission
hydrostaticReference
TransmissionHydro-Gear ZT-2800Reference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchelectricReference
Dimensions
Front tire10x4Reference
Rear tire20x9Reference
Lawn/turf front10x4Reference
Lawn/turf rear20x9Reference
Front axleCasterReference
Toro Z5200K attachments
52" mid-mount mower deckReference
Electrical
GroundnegativeReference
Battery CCA280Reference
Battery volts12Reference
52" Mower deck
Typemid-mount ToroReference
Type3-blade with manual liftReference
Cutting width132 cmReference
Cut height3 to 11 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
