Tractor · 1949Unverified

Turner Manufacturing Yeoman

Name: Turner Manufacturing Yeoman
Brand: Turner Manufacturing

Turner Manufacturing Yeoman — Row-Crop tractor · 40 hp. Reference specifications; pending source verification.

The Turner Manufacturing Yeoman is a compact tractor model with a rated output of 40 hp. It was manufactured from 1949 to 1955 and features a 4-cylinder diesel liquid-cooled engine. The tractor is equipped with two-wheel drive and a 4-speed gearbox, with a listed weight of 2494 kg. It is typically suited to working on areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

40 hp

Weight

2494 kg

Catalogue coverage

Variants represented

Richest spec table

45 rows

Recorded power

40 hp

Recorded weight

2494 kg

Transmissions

4-speed gear

Production years

1949-1955

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerTurner ManufacturingReference

Row-Crop tractorReference

Built in Wolverhampton, EnglandReference

Two-wheel driveReference

Final drivesspur gearReference

Differential lockmechanical rearReference

Manual steeringReference

Mechanical drum brakesReference

Open operator station. Cab optional.Reference

Engine

Turner Manufacturing 3.3L 4-cyl dieselReference

Fuel tank45.4 LReference

Engine29.8 kWReference

Belt (claimed)26.8 kWReference

Turner Manufacturing 4V95Reference

dieselReference

4-cylinderReference

liquid-cooled V4Reference

Displacement3.3 LReference

Bore/Stroke95 x 114 mmReference

Power29.8 kWReference

Air cleanerdry (early)Reference

Air cleaneroil bath (late)Reference

Compression19:1Reference

Rated RPM1500Reference

StarterelectricReference

Starter volts12Reference

Transmission

4-speed gearReference

TypegearReference

Gears4 forward and 1 reverseReference

Clutch279.4mm mechanical dry discReference

PTO & Hydraulics

Rear PTO Type540 (1.375)Reference

Dimensions

Wheelbase197 cmReference

Weight2494 kgReference

Front tire6.00-19Reference

Rear tire11-36Reference

Ag front6.00-19Reference

Ag rear11-36Reference

Length312 cmReference

Height (hood)148 cmReference

Height (exhaust)224 cmReference

Operating weight2494 kgReference

Clearance (front axle)45 cmReference

Clearance (rear axle)53 cmReference

Front tread121 to 182 cmReference

Rear tread132 to 182 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
