The Twin City 16-30 is a tractor model rated at approximately 16 hp, positioning it at the lighter end of its class. It was manufactured from 1918 to 1920. The tractor features a 4-cylinder liquid-cooled engine and two-wheel drive with a 1-speed gearbox. Its listed operating weight is 3538 kg, suitable for operations spanning up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
16 hp
Weight
3538 kg
Catalogue coverage
Variants represented
2
Richest spec table
25 rows
Recorded power
16 hp
Recorded weight
3538 kg
Transmissions
1-speed gear
Production years
1918-1920
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerTwin CityReference
Standard-tread tractorReference
Built in Minneapolis, Minnesota, USAReference
Total built702Reference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
9.7L 4-cyl keroseneReference
Drawbar (claimed)11.9 kWReference
Belt (claimed)22.4 kWReference
Plows3 (14-inch)Reference
keroseneReference
4-cylinderReference
liquid-cooled inlineReference
Displacement9.7 LReference
Bore/Stroke127 x 190 mmReference
Transmission
1-speed gearReference
TypegearReference
Gears1 forward and reverseReference
Dimensions
Weight3538 kgReference
Rear tire54x12Reference
Ag rear54x12 steelReference
Length454 cmReference
Width177 cmReference
Height182 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
