Tractor · 1920Unverified
Twin City 20-35
Twin City 20-35 · 20 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
20 hp
Max power
25.4 kW
Weight
3674 kg
Hover a source tag to verify
Overview
ManufacturerTwin CityReference
Built in Minneapolis, Minnesota, USAReference
Two-wheel driveReference
Engine
10.5L 4-cyl keroseneReference
Fuel tank151.4 LReference
Aux. fuel11.4 LReference
Drawbar (claimed)14.9 kWReference
Belt (claimed)26.1 kWReference
Plows6 (14-inch)Reference
Drawbar (tested)25.4 kWReference
Belt (tested)35.0 kWReference
keroseneReference
4-cylinderReference
liquid-cooled vertical, valve-in-headReference
Displacement10.5 LReference
Bore/Stroke140 x 171 mmReference
Rated RPM900Reference
Coolant capacity68.1 LReference
Belt power (max)35.0 kWReference
Max power25.4 kWReference
Transmission
2-speedReference
TransmissiongearReference
Gears2 forward and 1 reverseReference
Dimensions
Weight3674 kgReference
Front tire36x8.50Reference
Rear tire60x20Reference
Ag front36x8.50 (steel)Reference
Ag rear60x20 (steel)Reference
Length386 cmReference
Height185 cmReference
20-35 Serial Numbers
Location:front-left of transmissionReference
Test results
Kerosene October 1920Reference
Belt fuel use (max)22.7 l/hourReference
Drawbar performanceReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
