Tractor · 1916Unverified
Twin City 25-45
Twin City 25-45 — Standard-tread tractor · 25 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
25 hp
Weight
7030 kg
Hover a source tag to verify
Overview
ManufacturerTwin CityReference
Standard-tread tractorReference
Built in Minneapolis, Minnesota, USAReference
Two-wheel driveReference
Manual steeringReference
Steel canopy.Reference
Engine
Twin City 14.8L 4-cyl keroseneReference
Fuel tank249.8 LReference
Drawbar (claimed)18.6 kWReference
Belt (claimed)33.6 kWReference
Twin CityReference
keroseneReference
4-cylinderReference
liquid-cooled inlineReference
Displacement14.8 LReference
Bore/Stroke159 x 203 mmReference
Rated RPM600Reference
Coolant capacity325.6 LReference
Transmission
2-speed gearReference
TypegearReference
Gears2 forward and 1 reverseReference
Dimensions
Weight7030 kgReference
Length558 cmReference
Width203 cmReference
Height317 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
