Tractor · 1927Unverified
Twin City 27-44
Twin City 27-44 — Standard-tread tractor · 27 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
27 hp
Max power
25.9 kW
Weight
4173 kg
Hover a source tag to verify
Overview
ManufacturerTwin CityReference
Standard-tread tractorReference
Built in Minneapolis, Minnesota, USAReference
Total built840Reference
Two-wheel driveReference
Manual steeringReference
Open operator station. Canopy available.Reference
Engine
Twin City 10.5L 4-cyl keroseneReference
Fuel tank151.4 LReference
Aux. fuel5.7 LReference
Drawbar (claimed)20.1 kWReference
Belt (claimed)32.8 kWReference
Plows5 to 6Reference
Drawbar (tested)25.9 kWReference
Belt (tested)36.6 kWReference
Twin CityReference
keroseneReference
4-cylinderReference
liquid-cooled inlineReference
Displacement10.5 LReference
Bore/Stroke140 x 171 mmReference
Rated RPM900Reference
Starter typehand-crankReference
Oil capacity15.1 LReference
Coolant capacity68.1 LReference
Belt power (max)36.6 kWReference
Max power25.9 kWReference
Transmission
2-speed gearReference
TypegearReference
Gears2 forward and 1 reverseReference
Clutchdry discReference
Dimensions
Wheelbase246 cmReference
Weight4173 kgReference
Front tire36x8.50Reference
Rear tire60x20Reference
Ag front36x8.50 (steel)Reference
Ag rear60x20 (steel)Reference
Length386 cmReference
Width223 cmReference
Height185 cmReference
Shipping weight4173 kgReference
27-44 Serial Number Location
front-left of transmissionReference
Capacities
Diameter53 cmReference
Width21 cmReference
RPM466Reference
Speed780.29 meters/minReference
Test results
Kerosene 2-speed 2WDMay 20 - 27, 1926Link: Nebraska Tractor Test 122 fileReference
Belt fuel use (max)20.8 l/hourReference
Drawbar performanceReference
Max pull2558 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
