Tractor · 1929Unverified
Twin City KT
Twin City KT — Standard-tread tractor · 14 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
14 hp
Max power
14.1 kW
Weight
1950 kg
Hover a source tag to verify
Overview
ManufacturerTwin City (a part of Minneapolis-Moline)Reference
Standard-tread tractorReference
Built in Minneapolis, Minnesota, USAReference
Total built2,078Reference
Two-wheel driveReference
Final drivesbull gearReference
Manual steeringReference
Open operator station.Reference
Engine
Minneapolis 4.6L 4-cyl keroseneReference
Fuel tank90.8 LReference
Aux. fuel11.4 LReference
Drawbar (claimed)10.4 kWReference
Belt (claimed)17.2 kWReference
Drawbar (tested)14.1 kWReference
Belt (tested)19.3 kWReference
MinneapolisReference
keroseneReference
4-cylinderReference
liquid-cooled inlineReference
Displacement4.6 LReference
Bore/Stroke108 x 127 mmReference
Fuel systemcarburetorReference
Rated RPM1000Reference
Starter typehand-crankReference
Oil capacity11.4 LReference
Coolant capacity22.7 LReference
Belt power (max)19.3 kWReference
Max power14.1 kWReference
Transmission
3-speed gearReference
TypegearReference
Gears3 forward and 1 reverseReference
Clutchdry discReference
PTO & Hydraulics
Rear PTOtranmissionReference
Dimensions
Wheelbase198 cmReference
Weight1950 kgReference
Front tire28x5Reference
Rear tire42x10Reference
Ag front28x5 (steel)Reference
Ag rear42x10 (steel)Reference
Length332 cmReference
Width149 cmReference
Height163 cmReference
Flange rear axle69 mmReference
KT Serial Numbers
Location:Serial number on the top-right of transmissionReference
Capacities
Diameter35 cmReference
Width17 cmReference
RPM715Reference
Test results
Kerosene 3-speed 2WDMarch 24 - April 12, 1930Link: Nebraska Tractor Test 175 fileReference
Belt fuel use (max)9.8 l/hourReference
Drawbar performanceReference
Gear 2 used for power test.Reference
Max pull1512 kgReference
Gear 1 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
