Tractor · 1934Unverified
Twin City KTA
Twin City KTA — Standard-tread tractor · 20 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
20 hp
Max power
18.5 kW
Weight
1950 kg
Hover a source tag to verify
Overview
ManufacturerTwin City (a part of Minneapolis-Moline)Reference
Standard-tread tractorReference
Built in Minneapolis, Minnesota, USAReference
Total built4,552Reference
Two-wheel driveReference
Open operator stationReference
Engine
Minneapolis 4.6L 4-cyl distillateReference
Fuel tank90.8 LReference
Aux. fuel11.4 LReference
Drawbar (claimed)14.9 kWReference
Belt (claimed)22.4 kWReference
Drawbar (tested)18.5 kWReference
Belt (tested)25.1 kWReference
Minneapolis KEReference
distillateReference
4-cylinder 16-valveReference
liquid-cooled vertical I-headReference
Displacement4.6 LReference
Bore/Stroke108 x 127 mmReference
Rated RPM1150Reference
Firing order1-3-4-2Reference
Coolant capacity22.7 LReference
Belt power (max)25.1 kWReference
Max power18.5 kWReference
Transmission
3-speedReference
TransmissiongearReference
Gears3 forward and 1 reverseReference
Dimensions
Weight1950 kgReference
Front tire28x5Reference
Rear tire42x10Reference
Ag front28x5 steelReference
Ag rear42x10 steelReference
Length332 cmReference
Height163 cmReference
KTA Serial Number Location
Serial number plate on the left side of the Minneapolis-Moline KTA.Reference
KTA Serial Numbers
1934302200Reference
1935302372Reference
1936303826Reference
1937304702Reference
1938306282Reference
Final306751Reference
FAQ: How to read a serial number table.Reference
Test results
Distillate October 1935Reference
Belt fuel use (max)15.5 l/hourReference
Drawbar performanceReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
