Industrial Tractor · 1926Unverified
Twin City Road Chief
Twin City Road Chief — Industrial tractor · 17 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
17 hp
Weight
2426 kg
Hover a source tag to verify
Overview
ManufacturerTwin CityReference
Industrial tractorReference
Built in Minneapolis, Minnesota, USAReference
Two-wheel driveReference
Manual steeringReference
Mechanical contracting band brakesReference
Open operator station.Reference
Variants
17-28farm tractorReference
Road Chiefindustrial tractorReference
Engine
Twin-City 5.6L 4-cyl keroseneReference
Fuel tank113.6 LReference
Aux. fuel3.8 LReference
Drawbar (claimed)12.7 kWReference
Belt (claimed)20.9 kWReference
Twin-CityReference
keroseneReference
4-cylinderReference
liquid-cooled inlineReference
Displacement5.6 LReference
Bore/Stroke108 x 152 mmReference
Air cleanerdryReference
Rated RPM1075Reference
Starter typehand-crankReference
Coolant capacity39.7 LReference
Transmission
2-speed gearReference
TypegearReference
Gears2 forward and 1 reverseReference
Clutchdry discReference
Dimensions
Wheelbase213 cmReference
Weight2426 kgReference
Front tire34x6Reference
Rear tire50x20Reference
Industrial front34x6Reference
Industrial rear50x20 (solid rubber duals)Reference
Length353 cmReference
Width167 cmReference
Height167 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
