Tractor · Unverified
TYM T280
TYM T280 — ???? - 2001 Compact Utility tractor · 28 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
28 hp
Weight
1269 kg
Hover a source tag to verify
Overview
ManufacturerTYMReference
Compact Utility tractorReference
Built in South KoreaReference
Four-wheel driveReference
Differential lockmechanical rearReference
SteeringpowerReference
Wet disc brakesReference
Two-post ROPS.Reference
Engine
Kubota 1.5L 3-cyl dieselReference
Fuel tank26.1 LReference
Engine20.9 kWReference
Kubota D1503Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke84 x 91 mmReference
Power20.9 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speed synchromeshReference
TypesynchromeshReference
Gears16 forward and reverseReference
Clutchdry discReference
PTO & Hydraulics
Pump flow37.9 lpmReference
Rear TypeIReference
Controlposition and draft controlReference
Rear lift1020 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Dimensions
Wheelbase160 cmReference
Weight1269 kgReference
Front tire7-16Reference
Rear tire11.2-24Reference
Ag front7-16Reference
Ag rear11.2-24Reference
Length309 cmReference
Width127 cmReference
Height (ROPS)203 cmReference
Ground clearance33 cmReference
Front tread104 cmReference
Rear tread101 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
