Tractor · 2006Unverified
TYM T353
TYM T353 — 300 Series · 35 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
35 hp
Weight
1390 kg
Hover a source tag to verify
Overview
ManufacturerTYMReference
Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS.Reference
Variants
T35312-speed shuttleReference
T353HSThydrostaticReference
Engine
Mitsubishi 1.8L 4-cyl dieselReference
Engine (gross)26.1 kWReference
Mitsubishi S4L2Reference
dieselReference
4-cylinderReference
liquid-cooled inlineReference
Displacement1.8 LReference
Bore/Stroke78 x 92 mmReference
Power (gross)26.1 kWReference
Fuel systemindirect injectionReference
Air cleanerdual dry elementReference
Rated RPM2700Reference
StarterelectricReference
Starter volts12Reference
Oil capacity5.7 LReference
Coolant capacity7.0 LReference
Transmission
12-speed sync shuttleReference
hydrostaticReference
Typesync shuttleReference
Gears12 forward and reverseReference
Clutchsingle dry discReference
Oil capacity32.2 LReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
Oil capacity35.0 LReference
PTO & Hydraulics
Gear PTO (claimed)21.6 kWReference
Hydro PTO (claimed)19.4 kWReference
Gear Hydraulic system32.2 LReference
Hydro Hydraulic system35.0 LReference
Typeopen centerReference
Gear Capacity32.2 LReference
Hydro Capacity35.0 LReference
Pump flow23.8 lpmReference
Total flow40.1 lpmReference
Steering flow16.3 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift (at ends)1200 kgReference
Rear lift (at 24"/610mm)800 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulicReference
Rear PTO Type540/1000 (1.375)Reference
Mid PTOoptionalReference
Mid PTO Type2000Reference
Capacities
Fuel34.1 LReference
Front axle8.2 LReference
Dimensions
Wheelbase163 cmReference
Weight1390 kgReference
Front tire7.0-16Reference
Rear tire11.2-24Reference
Weight484 kgReference
Ag front7.0-16Reference
Ag rear11.2-24Reference
Industrial front27x10.5-15Reference
Industrial rear12.5x20Reference
Length320 cmReference
Width135 cmReference
Height (ROPS)240 cmReference
Ground clearance32 cmReference
TYM T353 attachments
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps50Reference
Charging volts12Reference
Battery volts12Reference
Attachment overview
TYM LT353 loaderReference
TYM LT353H loaderReference
TYM TX3500 loaderReference
BackhoeReference
TYM BT300 Backhoe
Backhoe typeTYM BT300 BackhoeReference
Transport height212 cmReference
2-Foot flat digging depth227 cmReference
Reach from pivot317 cmReference
Loading height183 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force1386 kgReference
Dipperstick force712 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
