Tractor · 2014Unverified
TYM T354
TYM T354 — Compact Utility tractor · 34 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
34 hp
Weight
1390 kg
Hover a source tag to verify
Overview
ManufacturerTYMReference
Compact Utility tractorReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Mechanical wet disc brakesReference
Two-post foldable ROPS.Reference
Engine
Yanmar 1.6L 3-cylReference
Fuel tank34.1 LReference
Engine (gross)25.5 kWReference
Yanmar 3TNV88-CRReference
3-cylinderReference
liquid-cooledReference
Displacement1.6 LReference
Bore/Stroke88 x 90 mmReference
EmissionsTier IVReference
Power (gross)25.5 kWReference
Compression19:1Reference
Rated RPM2800Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed syncronized shuttleReference
hydrostaticReference
Typesyncronized shuttleReference
Gears12 forward and reverseReference
Clutch225mm dry discReference
Four gears (1-4) in three ranges (low, medium, high) with mechanical left hand reverser lever. Gears shifts and shuttle shifts are synchronized, using the clutch.Reference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
PTO & Hydraulics
Typeopen center dual gear pumpReference
Valves1Reference
Total flow40.1 lpmReference
Rear TypeIReference
Rear lift (at ends)1200 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulic wet discReference
Rear PTO Type540/1000 (1.375)Reference
Dimensions
Wheelbase163 cmReference
Weight1390 kgReference
Front tire27x10.5-15Reference
Rear tire12.5x20Reference
Ag front27x10.5-15Reference
Ag rear12.5x20Reference
Lawn/turf front27x10.50LL-15Reference
Lawn/turf rear41x14.00-20Reference
Length320 cmReference
Width135 cmReference
Height (ROPS)240 cmReference
Ground clearance32 cmReference
TYM T354 attachments
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Attachment overview
TYM TX35 loaderReference
TYM TX35H loaderReference
Speeds
Reverse speeds are about 10% slower than forward.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
