Tractor · 2016Unverified
TYM T394
TYM T394 — Compact Utility tractor · 37 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
37 hp
Weight
1369 kg
Hover a source tag to verify
Overview
ManufacturerTYMReference
Compact Utility tractorReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS. Cab optional with air-conditioning.Reference
Engine
Yanmar 1.6L 3-cyl dieselReference
Fuel tank34.1 LReference
Engine (gross)27.9 kWReference
Yanmar 3TNV88Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.6 LReference
Bore/Stroke88 x 90 mmReference
Power (gross)27.9 kWReference
Fuel systemcommon rail direct injectionReference
Air cleanerdryReference
Rated RPM3000Reference
StarterelectricReference
Starter volts12Reference
Oil capacity5.7 LReference
Coolant capacity7.0 LReference
Transmission
12-speed shuttleReference
hydrostaticReference
TypeshuttleReference
Gears12 forward and reverseReference
Oil capacity35.0 LReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
PTO & Hydraulics
Typeopen centerReference
Pump flow24.2 lpmReference
Total flow41.6 lpmReference
Steering flow17.4 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift (at ends)1200 kgReference
Rear lift (at 24"/610mm)800 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Mid PTOindependentReference
Mid PTO Type2000Reference
Dimensions
Wheelbase167 cmReference
Weight1369 kgReference
Weight484 kgReference
Length320 cmReference
Width135 cmReference
Height (ROPS)239 cmReference
Ground clearance32 cmReference
TYM T394 attachments
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging amps55Reference
Battery volts12Reference
Attachment overview
Front-end loaderReference
BackhoeReference
TYM BY75 Backhoe
Backhoe typeTYM BY75 BackhoeReference
Transport height212 cmReference
Bucket width22 cmReference
Bucket width30 cmReference
Bucket width40 cmReference
Bucket width45 cmReference
2-Foot flat digging depth227 cmReference
Reach from pivot317 cmReference
Loading height183 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force1215 kgReference
Dipperstick force954 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
