The TYM T483 is a tractor rated at 48 hp — making it one of the more compact options in its class. Power comes from a 4-cylinder diesel liquid-cooled engine, driving through four-wheel drive with a hydrostatic transmission. Listed weight is 4189 to 4409 pounds, and it is aimed at jobs of around up to 200 ac. Available dimensions and performance figures follow in both unit systems.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
48 hp
Weight
4189 to 4409 pounds
Catalogue coverage
Variants represented
2
Richest spec table
35 rows
Recorded power
48 hp
Recorded weight
1900 kg
Transmissions
16-speed
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerTYMReference
Compact Utility tractorReference
Built in South KoreaReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Two-post ROPS. Cab optional.Reference
Engine
2.2L 4-cyl dieselReference
Fuel tank60.2 LReference
Engine35.8 kWReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.2 LReference
Power35.8 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speedReference
Gears16 forward and reverseReference
PTO & Hydraulics
Rear PTO Type560/728/1000Reference
Dimensions
Wheelbase193 cmReference
Weight4189 to 4409 poundsReference
Front tire9.5-18Reference
Rear tire13.6-28Reference
Standard tires (ag)Front: 9.5-18. Rear: 13.6-28Reference
Length384 cmReference
Width169 cmReference
Height (ROPS)264 cmReference
Height (cab)249 cmReference
Weight1900 kgReference
Weight1999 kgReference
Ground clearance37 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
