The TYM T502 is a tractor with a rated power output of 50 hp, positioned at the lighter end of its class. It features a 3-cylinder diesel liquid-cooled engine and four-wheel drive with a hydrostatic transmission. The tractor's operating weight is listed at 2699 kg, and it is suitable for operations covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
50 hp
Weight
2699 kg
Catalogue coverage
Variants represented
2
Richest spec table
33 rows
Recorded power
50 hp
Recorded weight
2699 kg
Transmissions
12-speed
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerTYMReference
Utility tractorReference
Built in South KoreaReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Cab standard.Reference
Engine
John Deere 2.9L 3-cyl dieselReference
Fuel tank70.0 LReference
Engine37.3 kWReference
John Deere 3029DReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.9 LReference
Bore/Stroke106 x 110 mmReference
Power37.3 kWReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speedReference
Gears12 forward and reverseReference
PTO & Hydraulics
Rear PTO Type561/760Reference
Dimensions
Weight2699 kgReference
Front tire9.5-20Reference
Rear tire14.9-28Reference
Ag front9.5-20Reference
Ag rear14.9-28Reference
Length403 cmReference
Width180 cmReference
Height (ROPS)247 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
