Tractor · Unverified

TYM T552

Name: TYM T552
Brand: TYM

TYM T552 — Utility tractor · 55 hp. Reference specifications; pending source verification.

The TYM T552 is a tractor rated at 55 hp — making it one of the more compact options in its class. Under the hood is a 3-cylinder diesel liquid-cooled engine, driving through four-wheel drive with a hydrostatic transmission. Listed weight is 2699 kg, and it is aimed at jobs of around up to 200 ac. Recorded specifications in UK and US units are listed below.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

55 hp

Weight

2699 kg

Catalogue coverage

Variants represented

Richest spec table

54 rows

Recorded power

55 hp

Recorded weight

2699 kg

Transmissions

24-speed

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerTYMReference

Utility tractorReference

Built in South KoreaReference

Four-wheel driveReference

Steeringhydrostatic powerReference

Wet disc brakesReference

Cab standard.Reference

Engine

John Deere 2.9L 3-cyl dieselReference

Fuel tank70.0 LReference

Engine41.0 kWReference

John Deere 3029DReference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement2.9 LReference

Bore/Stroke106 x 110 mmReference

Power41.0 kWReference

Rated RPM2500Reference

StarterelectricReference

Starter volts12Reference

Fuel TypeDieselReference

No of Cylinders3-cylinderReference

Rated engine speed2,500Reference

Bore and stroke4.19x4.33 inchesReference

Cooling systemliquid-cooledReference

Transmission

24-speedReference

Gears24 forward and reverseReference

forward and reverse options24 forward and reverseReference

PTO & Hydraulics

Rear PTO Type561/760Reference

Dimensions

Weight2699 kgReference

Front tire11.2-20Reference

Rear tire14.9-30Reference

Ag front11.2-20Reference

Ag rear14.9-30Reference

Length403 cmReference

Width180 cmReference

Height (ROPS)247 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

General

Make & ModelTYMReference

Country of manufacturerOption 1: Utility tractor\\nOption 2: South KoreaReference

Capacities

Capacity179 ciReference

Power

Rated Power55 hpReference

PTO

Rear PTO PowerAvailableReference

Rear PTO RPM561/760 RPMReference

Steering & brakes

Brakeswet discReference

Steering typehydrostatic powerReference

Dimensions & weight

Overall Height247.9 cmReference

Overall Length403.1 cmReference

Overall Width180.1 cmReference

Wheels & tyres

Rear Wheel TypeAg rear - 14.9-30Reference

Front Wheel TypeAg front - 11.2-20Reference

Operator station

Cab AvailabilityAvailableReference

Cab Air conditioning, temperature differentialCab standard.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
