Tractor · 2006Unverified
TYM T553
TYM T553 — Utility tractor · 55 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
55 hp
Hover a source tag to verify
Overview
ManufacturerTYMReference
Utility tractorReference
Built in South KoreaReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Cab standard.Reference
Engine
Caterpillar 2.2L 4-cyl dieselReference
Fuel tank70.0 LReference
Engine41.0 kWReference
CaterpillarReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.2 LReference
Bore/Stroke84 x 100 mmReference
Power41.0 kWReference
Compression23.3:1Reference
Rated RPM2600Reference
Firing order1-3-4-2Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speed sync shuttleReference
Typesync shuttleReference
Gears16 forward and reverseReference
Oil capacity34.8 LReference
Four synchronized gears (1-4) in four ranges with synchronized shuttle shift. Tractor must be stopped to shift range.Reference
PTO & Hydraulics
Rear PTO Type561/760Reference
Dimensions
Wheelbase212 cmReference
Front tire11.2-20Reference
Rear tire14.9-30Reference
Standard tires (ag)Front: 11.2-20. Rear: 14.9-30Reference
Length377 cmReference
Width182 cmReference
Height (cab)249 cmReference
Ground clearance36 cmReference
T553 Serial Numbers
Location:Serial number plate on the front right of the tractor frame, above the front axle.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Speeds
Reverse speeds are 15% slower than forward.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
