The TYM T653 is a tractor rated at 65 hp, positioned in the middle of its class for power. It features a 3-cylinder turbocharged diesel liquid-cooled engine, which drives the tractor through a four-wheel drive system with a hydrostatic transmission. The listed weight of the TYM T653 is 2484 kg, and it is suitable for tasks involving approximately 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
65 hp
Weight
2484 kg
Catalogue coverage
Variants represented
2
Richest spec table
31 rows
Recorded power
65 hp
Recorded weight
2484 kg
Transmissions
24-speed
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerTYMReference
Utility tractorReference
Built in South KoreaReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Cab standard.Reference
Engine
3-cyl dieselReference
Fuel tank71.9 LReference
Engine48.5 kWReference
turbocharged dieselReference
3-cylinderReference
liquid-cooledReference
Power48.5 kWReference
Rated RPM2200Reference
StarterelectricReference
Starter volts12Reference
Transmission
24-speedReference
Gears24 forward and reverseReference
PTO & Hydraulics
Rear PTO Type540/540EReference
Dimensions
Wheelbase211 cmReference
Weight2484 kgReference
Front tire11.2-20Reference
Rear tire14.9-30Reference
Standard tires (ag)Front: 11.2-20. Rear: 14.9-30Reference
Length372 cmReference
Width183 cmReference
Height (cab)254 cmReference
Ground clearance41 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
