Tractor · Unverified
TYM T680
TYM T680 — ???? - 2006 Utility tractor · 68 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
68 hp
Weight
3020 kg
Hover a source tag to verify
Overview
ManufacturerTYMReference
Utility tractorReference
Built in South KoreaReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Cab standard.Reference
Engine
John Deere 2.9L 3-cyl dieselReference
Fuel tank83.3 LReference
Engine50.7 kWReference
John Deere 3029DReference
turbocharged dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.9 LReference
Bore/Stroke106 x 110 mmReference
Power50.7 kWReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speedReference
Gears16 forward and reverseReference
PTO & Hydraulics
Rear PTO Type564/799Reference
Dimensions
Wheelbase211 cmReference
Weight3020 kgReference
Front tire11.2-24Reference
Rear tire16.9-30Reference
Ag front11.2-24Reference
Ag rear16.9-30Reference
Length403 cmReference
Width195 cmReference
Height (ROPS)260 cmReference
Ground clearance49 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
