Tractor · 2015Unverified
TYM T954
TYM T954 — Utility tractor · 93 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
93 hp
Weight
3940 kg
Hover a source tag to verify
Overview
ManufacturerTYMReference
Utility tractorReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Cab standard with air-conditioning.Reference
Variants
T954 SC12-speedReference
T954 SP32-speedReference
Engine
Doosan Infracore 3.4L 4-cyl dieselReference
Fuel tank110.1 LReference
Exhaust fluid (DEF)20.1 LReference
Engine (gross)69.0 kWReference
Doosan Infracore DL03-LEA05Reference
turbocharged dieselReference
4-cylinder 16-valveReference
liquid-cooled inlineReference
Displacement3.4 LReference
Bore/Stroke98 x 113 mmReference
Power (gross)69.0 kWReference
Air cleanerdryReference
Rated RPM2300Reference
Torque400.0 NmReference
Torque RPM1400Reference
StarterelectricReference
Starter volts12Reference
Transmission
32-speed two-speed power shiftReference
12-speed power shuttleReference
Typetwo-speed power shiftReference
Gears32 forward and reverseReference
Clutchdry discReference
Four synchronized gears (1-4) in four ranges with two-speed push-button power shift. Left-hand power shuttle. Tractor must be stopped, and clutch used, to shift range.Reference
Typepower shuttleReference
Gears12 forward and reverseReference
Four synchronized gears in four ranges with left-hand power shuttle. Tractor must be stopped, and clutch used, to shift range.Reference
PTO & Hydraulics
Typeopen centerReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear PTOindependentReference
Rear PTO Type540/750/1000 (1.375)Reference
Dimensions
Weight3940 kgReference
Front tire13.6-24Reference
Rear tire16.9-34Reference
Standard tires (ag)Front: 13.6-24. Rear: 16.9-34Reference
Length450 cmReference
Height274 cmReference
Ground clearance46 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
