Tractor · Unverified
TYM TL493
TYM TL493 — Compact Utility tractor · 49 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
49 hp
Hover a source tag to verify
Overview
ManufacturerTYMReference
Compact Utility tractorReference
Built in South KoreaReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Two-post ROPS.Reference
Engine
Yanmar 2.0L 4-cyl dieselReference
Fuel tank42.0 LReference
Engine36.5 kWReference
YanmarReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.0 LReference
Power36.5 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speedReference
Gears16 forward and reverseReference
PTO & Hydraulics
Rear PTO Type540/750/1000Reference
Dimensions
Wheelbase180 cmReference
Front tire8.0-16Reference
Rear tire12.4-24Reference
Standard tires (ag)Front: 8.0-16. Rear: 12.4-24Reference
Optional tires (ag)Front: 10-16. Rear: 13.6-26Reference
Length311 cmReference
Width150 cmReference
Height (ROPS)248 cmReference
Ground clearance34 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
