Tractor · 2013Unverified
TYM TX1500
TYM TX1500 — Row-Crop tractor · 145 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
145 hp
Weight
5656 kg
Hover a source tag to verify
Overview
ManufacturerTYMReference
Row-Crop tractorReference
Built in South KoreaReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Cab standard.Reference
Engine
Perkins 6.6L 6-cyl dieselReference
Fuel tank249.8 LReference
Engine108.1 kWReference
PerkinsReference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.6 LReference
Power108.1 kWReference
Rated RPM2200Reference
StarterelectricReference
Starter volts12Reference
Transmission
continuously variable transmissionReference
TransmissionZFReference
Typecontinuously variable transmissionReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Rear TypeIIIReference
Rear lift5601 kgReference
Rear PTOindependentReference
Rear PTO Type540/750/1000/1400Reference
Dimensions
Wheelbase277 cmReference
Weight5656 kgReference
Front tire380/85R28Reference
Rear tire460/85R38Reference
Standard tires (ag)Front: 380/85R28. Rear: 460/85R38Reference
Optional tires (ag)Front: 420/70R28. Rear:Reference
Optional tires (ag)Front: 520/70R38. Rear:Reference
Length491 cmReference
Width232 cmReference
Height (cab)287 cmReference
Ground clearance42 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
