Tractor · 2013Unverified
TYM TX803
TYM TX803 — Utility tractor · 80 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
80 hp
Hover a source tag to verify
Overview
ManufacturerTYMReference
Utility tractorReference
Built in South KoreaReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Cab standard.Reference
Engine
Cummins 3.3L 4-cyl dieselReference
Fuel tank110.1 LReference
Engine59.7 kWReference
Cummins B3.3Reference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.3 LReference
Bore/Stroke95 x 115 mmReference
Power59.7 kWReference
Rated RPM2400Reference
StarterelectricReference
Starter volts12Reference
Transmission
24-speedReference
Gears24 forward and reverseReference
PTO & Hydraulics
Rear PTO Type540/750/1000Reference
Dimensions
Wheelbase219 cmReference
Front tire11.2-24Reference
Rear tire16.9-30Reference
Standard tires (ag)Front: 11.2-24. Rear: 16.9-30Reference
Length393 cmReference
Width194 cmReference
Height (cab)267 cmReference
Ground clearance46 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
