Tractor · 1981Unverified
Ursus 1002
Ursus 1002 — A Series · 100 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
100 hp
Hover a source tag to verify
Overview
ManufacturerUrsusReference
Row-Crop tractorReference
Two-wheel driveReference
Steeringhydraulic powerReference
Engine
Ursus 4.6L 4-cyl dieselReference
Engine74.6 kWReference
UrsusReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.6 LReference
Bore/Stroke110 x 120 mmReference
Power74.6 kWReference
Compression16:1Reference
Rated RPM2200Reference
Starter volts12Reference
Transmission
16-speedReference
Gears16 forward and 8 reverseReference
PTO & Hydraulics
Rear PTO Type540/1000Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
