Tractor · 1991Unverified

Ursus 1134

Name: Ursus 1134
Brand: Ursus

Ursus 1134 — 30 Series · 85 hp. Reference specifications; pending source verification.

The Ursus 1134 is a tractor with a rated power output of 85 hp, a mid-range figure within its class. Manufactured from 1991 to 2009, the 1134 is equipped with a 4-cylinder turbocharged diesel liquid-cooled engine, paired with a powershift transmission and four-wheel drive. Its listed operating weight is 4819 kg, making it suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

85 hp

Weight

4819 kg

Catalogue coverage

Variants represented

Richest spec table

69 rows

Recorded power

85 hp

Recorded weight

4819 kg

Transmissions

16-speed two-speed power shift

Production years

1991-2009

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerUrsusReference

Built in Warsaw, PolandReference

Four-wheel driveReference

Differential lockmechanical rearReference

Power steeringReference

Dry disc brakesReference

Cab standard with heat.Reference

Variants

11322WDReference

11344WDReference

Engine

Zetor 4.6L 4-cyl dieselReference

Engine70.5 kWReference

Zetor Z 8002.12Reference

turbocharged dieselReference

4-cylinderReference

liquid-cooledReference

Displacement4.6 LReference

Bore/Stroke110 x 120 mmReference

Power70.5 kWReference

Fuel systemdirect injectionReference

Air cleaneroil bathReference

Compression17:1Reference

Rated RPM2200Reference

Torque333.0 NmReference

Torque RPM1650Reference

StarterelectricReference

Starter volts24Reference

Starter power4.8 kWReference

Oil capacity10.0 LReference

Coolant capacity23.0 LReference

Transmission

16-speed two-speed power shiftReference

Typetwo-speed power shiftReference

Gears16 forward and 8 reverseReference

Clutch350mm hydraulic dry discReference

Oil capacity46.0 LReference

Four gears (1-4) in two ranges (I/II) plus reverse range (R) with two-speed power shift.Reference

PTO & Hydraulics

PTO (claimed)63.7 kWReference

Hydraulic system46.0 LReference

Capacity46.0 LReference

Pump flow40.9 lpmReference

Rear TypeIIReference

Controlposition and draft controlReference

Rear lift4125 kgReference

Rear PTOindependentReference

ClutchhydraulicReference

Rear PTO Type540/1000 (1.375)Reference

Engine RPM540@1890Reference

Engine RPM1000@1920Reference

Front PTO1000Reference

Capacities

Fuel129.8 LReference

Dimensions

Wheelbase239 cmReference

Weight4819 kgReference

Front tire12.4-24Reference

Rear tire18.4-34Reference

Standard tires (ag)Front: 12.4-24. Rear: 18.4-34Reference

Length414 cmReference

Width208 cmReference

Height (cab)293 cmReference

Height (exhaust)296 cmReference

Ballasted weight5499 kgReference

Ground clearance38 cmReference

Front tread151/161/170/181 cmReference

Rear tread150 to 187 cmReference

Electrical

Charging systemalternatorReference

Charging amps55Reference

Charging volts12Reference

Batteries2Reference

Battery volts12Reference

Battery AH135Reference

Speeds

With 18.4-34 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
