Tractor · 1983Unverified
Ursus 1214
Ursus 1214 — A Series · 120 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
120 hp
Weight
4820 kg
Hover a source tag to verify
Overview
ManufacturerUrsusReference
Row-Crop tractorReference
Four-wheel driveReference
Steeringhydraulic powerReference
Engine
Ursus 6.8L 6-cyl dieselReference
Fuel tank129.8 LReference
Engine89.5 kWReference
UrsusReference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.8 LReference
Bore/Stroke110 x 120 mmReference
Power89.5 kWReference
Compression17:1Reference
Rated RPM2200Reference
Starter volts12Reference
Transmission
16-speedReference
Gears16 forward and 8 reverseReference
PTO & Hydraulics
Pump flow40.9 lpmReference
Rear lift4000 kgReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase270 cmReference
Weight4820 kgReference
Front tire14.9-24Reference
Rear tire18.4-34Reference
Ag front14.9-24Reference
Ag rear18.4-34Reference
Length445 cmReference
Height255 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
