Tractor · 1991Unverified
Ursus 1232
Ursus 1232 — 30 Series · 103 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
103 hp
Weight
4570 kg
Hover a source tag to verify
Overview
ManufacturerUrsusReference
Built in Warsaw, PolandReference
Two-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Dry disc brakesReference
Cab standard with heat.Reference
Variants
12322WDReference
12344WDReference
Engine
Zetor 6.8L 6-cyl dieselReference
Engine87.6 kWReference
Zetor Z 8701.12Reference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.8 LReference
Bore/Stroke110 x 120 mmReference
Power87.6 kWReference
Fuel systemdirect injectionReference
Air cleaneroil bathReference
Compression17:1Reference
Rated RPM2200Reference
Torque412.5 NmReference
Torque RPM1600Reference
StarterelectricReference
Starter volts24Reference
Starter power5.6 kWReference
Oil capacity19.0 LReference
Coolant capacity26.0 LReference
Transmission
16-speed two-speed power shiftReference
Typetwo-speed power shiftReference
Gears16 forward and 8 reverseReference
Clutch380mm hydraulic dry discReference
Oil capacity46.0 LReference
Four gears (1-4) in two ranges (I/II) plus reverse range (R) with two-speed power shift.Reference
PTO & Hydraulics
PTO (claimed)76.7 kWReference
Hydraulic system46.0 LReference
Capacity46.0 LReference
Pump flow40.9 lpmReference
Rear TypeIIReference
Rear TypeIIIReference
Controlposition and draft controlReference
Rear lift4125 kgReference
Rear lift5499 kgReference
Rear PTOindependentReference
ClutchhydraulicReference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@1890Reference
Engine RPM1000@1920Reference
Capacities
Fuel129.8 LReference
Dimensions
Wheelbase269 cmReference
Weight4570 kgReference
Front tire7.50-20Reference
Rear tire18.4-34Reference
Standard tires (ag)Front: 7.50-20. Rear: 18.4-34Reference
Length445 cmReference
Width196 cmReference
Height (cab)293 cmReference
Height (exhaust)297 cmReference
Ballasted weight5130 kgReference
Ground clearance43 cmReference
Front tread135/150/165/180 cmReference
Rear tread150 to 187 cmReference
Electrical
Charging systemalternatorReference
Charging amps55Reference
Charging volts12Reference
Batteries2Reference
Battery volts12Reference
Battery AH135Reference
Speeds
With 18.4-34 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
