Tractor · 1987Unverified
Ursus 1614
Ursus 1614 · 133 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
133 hp
Weight
5030 kg
Hover a source tag to verify
Overview
ManufacturerUrsusReference
Built in Warsaw, PolandReference
Drive4x4 4WDReference
Power steeringReference
Hydraulic dry disc brakesReference
Trailer brakespneumaticReference
Cab standard with air-conditioning.Reference
Engine
Zetor 6.8L 6-cyl dieselReference
Fuel tank200.2 LReference
Engine115.6 kWReference
Zetor Z8602.1Reference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.8 LReference
Bore/Stroke110 x 120 mmReference
Power115.6 kWReference
Fuel systemdirect injectionReference
Air cleaneroil bathReference
Compression17:1Reference
Rated RPM2200Reference
Torque532.1 NmReference
Torque RPM1600Reference
StarterelectricReference
Starter volts24Reference
Starter power5.6 kWReference
Oil capacity18.9 LReference
Coolant capacity29.0 LReference
Coolant capacity30.6 LReference
Transmission
12-speed two-speed power shiftReference
Typetwo-speed power shiftReference
Gears12 forward and 6 reverseReference
Clutch380mm dry discReference
Three gears (1-3) in two ranges (low/high), plus reverse range, with two-speed hydraulic power shift.Reference
PTO & Hydraulics
PTO (claimed)99.2 kWReference
Pump flow40.9 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift5501 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Rear PTO Type1000 (1.75)Reference
Engine RPM540@1890Reference
Engine RPM1000@1920Reference
Dimensions
Wheelbase269 cmReference
Weight5030 kgReference
Front tire14.9-24Reference
Rear tire18.4-38Reference
Ag front14.9-24Reference
Ag rear18.4-38Reference
Length458 cmReference
Width227 cmReference
Height (cab)275 cmReference
Ground clearance46 cmReference
Front tread151/161/170/181 cmReference
Rear tread165/172/180/187 cmReference
Electrical
Charging systemalternatorReference
Charging amps55Reference
Batteries4Reference
Battery volts6Reference
Battery AH120Reference
Speeds
With 18.4-38 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
