Tractor · 2006Unverified
Ursus 1654
Ursus 1654 — 30 Series · 140 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
140 hp
Weight
5919 kg
Hover a source tag to verify
Overview
ManufacturerUrsusReference
Built in Warsaw, PolandReference
Four-wheel driveReference
Power steeringReference
Dry disc brakesReference
Cab standard with heat.Reference
Engine
Zetor 7.3L 6-cyl dieselReference
Engine118.0 kWReference
Zetor Z 8604.035Reference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement7.3 LReference
Bore/Stroke110 x 128 mmReference
Power118.0 kWReference
Fuel systemdirect injectionReference
Rated RPM2200Reference
Torque667.2 NmReference
Starter typeelectricReference
Transmission
16-speed two-speed power shiftReference
Typetwo-speed power shiftReference
Gears16 forward and 8 reverseReference
Four gears (1-4) in two ranges (I/II) plus reverse range (R) with two-speed power shift.Reference
PTO & Hydraulics
PTO (claimed)104.0 kWReference
Pump flow54.9 lpmReference
Rear TypeIIReference
Rear TypeIIIReference
Rear lift6700 kgReference
Rear PTOindependentReference
ClutchhydraulicReference
Dimensions
Wheelbase270 cmReference
Weight5919 kgReference
Front tire14.9R28Reference
Rear tire20.8R38Reference
Standard tires (ag)Front: 14.9R28. Rear: 20.8R38Reference
Length449 cmReference
Ballasted weight7110 kgReference
Ground clearance48 cmReference
Electrical
Charging systemalternatorReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
