Tractor · 2009Unverified
Ursus 1674 Forte
Ursus 1674 Forte · 156 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
156 hp
Weight
6520 kg
Hover a source tag to verify
Overview
ManufacturerUrsusReference
Built in Warsaw, PolandReference
Four-wheel driveReference
Power steeringReference
Cab standard with available air-conditioning.Reference
Engine
Perkins 6.6L 6-cyl dieselReference
Fuel tank355.0 LReference
Engine116.5 kWReference
Perkins 1106D-E66TAReference
turbocharged aftercooled dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.6 LReference
Bore/Stroke108 x 120 mmReference
EmissionsStage IIIAReference
Power116.5 kWReference
Torque683.2 NmReference
Torque RPM1400Reference
Starter typeelectricReference
Transmission
16-speedReference
Gears16 forward and 8 reverseReference
Clutchdry discReference
PTO & Hydraulics
Pump flow79.9 lpmReference
Rear TypeIIIReference
Rear TypeIIReference
Rear lift6999 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Dimensions
Weight6520 kgReference
Front tire14.9R28Reference
Rear tire20.8R38Reference
Standard tires (ag)Front: 14.9R28. Rear: 20.8R38Reference
Optional tires (ag)Front: 420/70R28. Rear:Reference
Optional tires (ag)Front: 580/70R38. Rear:Reference
Length459 cmReference
Width230 cmReference
Height314 cmReference
Electrical
Charging systemalternatorReference
Charging amps100Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
