The Ursus 3724 Piko is a tractor rated at approximately 50 hp, which positions it at the lighter end of its class. It was manufactured from 2009 to 2011. The tractor features a 3-cylinder diesel liquid-cooled engine, combined with four-wheel drive and a 12-speed gearbox. Its listed operating weight is 3155 kg, making it suitable for operations covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
50 hp
Weight
3155 kg
Catalogue coverage
Variants represented
2
Richest spec table
38 rows
Recorded power
50 hp
Recorded weight
3155 kg
Transmissions
12-speed
Production years
2009-2011
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerUrsusReference
Built in Warsaw, PolandReference
Four-wheel driveReference
Power steeringReference
Cab standard with available air-conditioning.Reference
Engine
Perkins 3.3L 3-cyl dieselReference
Fuel tank104.8 LReference
Engine36.9 kWReference
Perkins 1103D-33Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement3.3 LReference
Bore/Stroke105 x 127 mmReference
EmissionsStage IIIAReference
Power36.9 kWReference
Torque196.1 NmReference
Torque RPM1400Reference
Starter typeelectricReference
Transmission
12-speedReference
8-speedReference
Gears12 forward and 4 reverseReference
Clutchdry discReference
Gears8 forward and reverseReference
PTO & Hydraulics
Pump flow45.0 lpmReference
Rear TypeIIReference
Rear lift2399 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Dimensions
Weight3155 kgReference
Front tire9.5R24Reference
Rear tire380/85R28Reference
Standard tires (ag)Front: 9.5R24. Rear: 380/85R28Reference
Length346 cmReference
Width181 cmReference
Height264 cmReference
Electrical
Charging systemalternatorReference
Charging amps55Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
