The Ursus 4024 is a compact tractor, with a rated output of 47 hp, making it one of the more compact options in its class. It was manufactured from 2007 to 2009 and features a 3-cylinder diesel liquid-cooled engine, which powers four-wheel drive through an 8-speed gearbox. The listed weight of the tractor is 3155 kg, and it is designed for use on areas of up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
47 hp
Weight
3155 kg
Catalogue coverage
Variants represented
2
Richest spec table
40 rows
Recorded power
47 hp
Recorded weight
3155 kg
Transmissions
8-speed
Production years
2007-2009
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerUrsusReference
Utility tractorReference
Built in Warsaw, PolandReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Cab standard with heater.Reference
Variants
40222WDReference
Engine
Perkins 3.3L 3-cyl dieselReference
Fuel tank50.0 LReference
Engine39.5 kWReference
Perkins 1103C-33Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement3.3 LReference
Bore/Stroke105 x 127 mmReference
Power39.5 kWReference
Starter typeelectricReference
Transmission
8-speedReference
12-speedReference
Gears8 forward and 2 reverseReference
Gears12 forward and 4 reverseReference
PTO & Hydraulics
PTO (claimed)34.8 kWReference
Total flow45.0 lpmReference
Rear lift1329 kgReference
Rear lift2800 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@1893Reference
Dimensions
Wheelbase216 cmReference
Weight3155 kgReference
Front tire9.5R24Reference
Rear tire14.9R28Reference
Standard tires (ag)Front: 9.5R24. Rear: 14.9R28Reference
