Tractor · 1988Unverified
Ursus 4514
Ursus 4514 · 59 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
59 hp
Weight
6107 to 7275 pounds
Hover a source tag to verify
Overview
ManufacturerUrsusReference
Built in Warsaw, PolandReference
Four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Mechanical wet disc brakesReference
Cab optional with available heater.Reference
Variants
45122WDReference
45144WDReference
Engine
Ursus 3.9L 4-cyl dieselReference
Engine49.2 kWReference
Ursus 4390Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.9 LReference
Bore/Stroke98 x 127 mmReference
Power49.2 kWReference
Fuel systemdirect injectionReference
Air cleaneroil bathReference
Pre-heatingglow plugsReference
Compression16:1Reference
Rated RPM2000Reference
Torque245.0 NmReference
Torque RPM1400Reference
Starter volts12Reference
Starter power3.0 kWReference
Oil capacity7.0 LReference
Coolant capacity13.9 LReference
Coolant capacity15.5 LReference
Transmission
8-speed gearReference
12-speed creeperReference
TypegearReference
Gears8 forward and 2 reverseReference
Clutchdry discReference
Oil capacity44.0 LReference
TypecreeperReference
Gears12 forward and 3 reverseReference
PTO & Hydraulics
PTO (claimed)44.0 kWReference
Hydraulic system43.9 LReference
Capacity43.9 LReference
Pump flow26.1 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift2399 kgReference
Rear lift2799 kgReference
Rear PTOliveReference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@1686Reference
Engine RPM1000@1692Reference
Capacities
Fuel79.9 LReference
Dimensions
Wheelbase230 cmReference
Weight6107 to 7275 poundsReference
Front tire11.2R24Reference
Rear tire16.9R30Reference
Standard tires (ag)Front: 11.2R24. Rear: 16.9R30Reference
Length370 cmReference
Width184 cmReference
Height (cab)252 cmReference
Height (exhaust)258 cmReference
Clearance (rear axle)46 cmReference
Clearance (drawbar)28 cmReference
Front tread147 to 181 cmReference
Rear tread135 to 221 cmReference
ROPS2770 kgReference
Cab3299 kgReference
ROPS Ballasted3160 kgReference
Cab Ballasted3690 kgReference
Electrical
Charging systemalternatorReference
Charging amps55Reference
Battery volts12Reference
Battery AH120Reference
Speeds
With 16.9R30 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
