Tractor · 2007Unverified
Ursus 5024
Ursus 5024 — Utility tractor · 59 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
59 hp
Weight
3404 kg
Hover a source tag to verify
Overview
ManufacturerUrsusReference
Utility tractorReference
Built in Warsaw, PolandReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Cab standard with heater.Reference
Engine
Perkins 4.4L 4-cyl dieselReference
Fuel tank79.9 LReference
Engine50.0 kWReference
Perkins 1104C-44Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.4 LReference
Bore/Stroke105 x 127 mmReference
Power50.0 kWReference
Starter typeelectricReference
Transmission
8-speedReference
12-speedReference
Gears8 forward and 2 reverseReference
Gears12 forward and 4 reverseReference
PTO & Hydraulics
PTO (claimed)44.0 kWReference
Total flow62.1 lpmReference
Rear lift2800 kgReference
Rear lift3200 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@1893Reference
Engine RPM1000@1900Reference
Dimensions
Wheelbase2266 cmReference
Weight3404 kgReference
Front tire12.4R24Reference
Rear tire16.9R34Reference
Standard tires (ag)Front: 12.4R24. Rear: 16.9R34Reference
Optional tires (ag)Front: 360/70R24. Rear: 480/70R34Reference
Length371 cmReference
Width185 cmReference
Height264 cmReference
Ballasted weight4179 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
