Tractor · 2009Unverified

Ursus 5524 Mido

Name: Ursus 5524 Mido
Brand: Ursus

Ursus 5524 Mido · 74 hp. Reference specifications; pending source verification.

The Ursus 5524 Mido is a tractor model with a rated power output of 74 hp, positioning it centrally within its class. Manufactured between 2009 and 2011, the tractor features a 4-cylinder turbocharged diesel liquid-cooled engine, paired with a 12-speed gearbox and four-wheel drive. Its listed weight is 3905 kg, suitable for tasks of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

74 hp

Weight

3905 kg

Catalogue coverage

Variants represented

Richest spec table

40 rows

Recorded power

74 hp

Recorded weight

3905 kg

Transmissions

12-speed

Production years

2009-2011

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerUrsusReference

Built in Warsaw, PolandReference

Four-wheel driveReference

Power steeringReference

Cab standard with available air-conditioning.Reference

Engine

Perkins 4.4L 4-cyl dieselReference

Fuel tank180.2 LReference

Engine55.5 kWReference

Perkins 1104D-44TReference

turbocharged dieselReference

4-cylinderReference

liquid-cooledReference

Displacement4.4 LReference

Bore/Stroke108 x 120 mmReference

EmissionsStage IIIAReference

Power55.5 kWReference

Torque307.0 NmReference

Torque RPM1400Reference

Starter typeelectricReference

Transmission

12-speedReference

8-speedReference

Gears12 forward and 4 reverseReference

Clutchdry discReference

Gears8 forward and reverseReference

PTO & Hydraulics

Pump flow62.1 lpmReference

Rear TypeIIReference

Rear lift2399 kgReference

Rear lift3850 kgReference

Rear PTOindependentReference

Rear PTO Type540/1000Reference

Dimensions

Weight3905 kgReference

Front tire12.4R24Reference

Rear tire16.9R34Reference

Standard tires (ag)Front: 12.4R24. Rear: 16.9R34Reference

Optional tires (ag)Front: 360/70R24. Rear: 480/70R34Reference

Length389 cmReference

Width219 cmReference

Height264 cmReference

Electrical

Charging systemalternatorReference

Charging amps55Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
