Tractor · 2009Unverified
Ursus 5524 Mido
Ursus 5524 Mido · 74 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
74 hp
Weight
3905 kg
Hover a source tag to verify
Overview
ManufacturerUrsusReference
Built in Warsaw, PolandReference
Four-wheel driveReference
Power steeringReference
Cab standard with available air-conditioning.Reference
Engine
Perkins 4.4L 4-cyl dieselReference
Fuel tank180.2 LReference
Engine55.5 kWReference
Perkins 1104D-44TReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.4 LReference
Bore/Stroke108 x 120 mmReference
EmissionsStage IIIAReference
Power55.5 kWReference
Torque307.0 NmReference
Torque RPM1400Reference
Starter typeelectricReference
Transmission
12-speedReference
8-speedReference
Gears12 forward and 4 reverseReference
Clutchdry discReference
Gears8 forward and reverseReference
PTO & Hydraulics
Pump flow62.1 lpmReference
Rear TypeIIReference
Rear lift2399 kgReference
Rear lift3850 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Dimensions
Weight3905 kgReference
Front tire12.4R24Reference
Rear tire16.9R34Reference
Standard tires (ag)Front: 12.4R24. Rear: 16.9R34Reference
Optional tires (ag)Front: 360/70R24. Rear: 480/70R34Reference
Length389 cmReference
Width219 cmReference
Height264 cmReference
Electrical
Charging systemalternatorReference
Charging amps55Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
