Tractor · 2009Unverified
Ursus 8024 Mido
Ursus 8024 Mido · 109 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
109 hp
Weight
4100 kg
Hover a source tag to verify
Overview
ManufacturerUrsusReference
Built in Warsaw, PolandReference
Four-wheel driveReference
Power steeringReference
Cab standard with available air-conditioning.Reference
Engine
Perkins 4.4L 4-cyl dieselReference
Fuel tank180.2 LReference
Engine81.0 kWReference
Perkins 1104D-44TAReference
turbocharged aftercooled dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.4 LReference
Bore/Stroke108 x 120 mmReference
EmissionsStage IIIAReference
Power81.0 kWReference
Torque416.0 NmReference
Torque RPM1400Reference
Starter typeelectricReference
Transmission
12-speedReference
8-speedReference
Gears12 forward and 4 reverseReference
Clutchdry discReference
Gears8 forward and reverseReference
PTO & Hydraulics
Pump flow62.1 lpmReference
Rear TypeIIReference
Rear lift4500 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Dimensions
Weight4100 kgReference
Front tire380/70R24Reference
Rear tire480/70R34Reference
Standard tires (ag)Front: 380/70R24. Rear: 480/70R34Reference
Length400 cmReference
Width219 cmReference
Height275 cmReference
Electrical
Charging systemalternatorReference
Charging amps55Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
