Tractor · 1984Unverified
Ursus 914
Ursus 914 · 64 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
64 hp
Weight
4419 kg
Hover a source tag to verify
Overview
ManufacturerUrsusReference
Built in Warsaw, PolandReference
The Ursus 914 is similar to the Zetor 8145.Reference
Drive4x4 4WDReference
Differential lockmechanical rear, front optionalReference
Power steeringReference
Hydraulic dry disc brakesReference
Trailer brakespneumaticReference
Variants
9122WDReference
9144WDReference
Engine
Zetor 4.6L 4-cyl dieselReference
4.6L 4-cyl dieselReference
Engine74.6 kWReference
Zetor Z8401.1Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.6 LReference
Bore/Stroke110 x 120 mmReference
Power59.7 kWReference
Fuel systemdirect injectionReference
Air cleaneroil bathReference
Rated RPM2200Reference
Torque268.1 NmReference
Torque RPM1450Reference
StarterelectricReference
Starter volts12Reference
Starter power3.0 kWReference
Oil capacity10.0 LReference
Coolant capacity23.0 LReference
Coolant capacity24.6 LReference
turbocharged dieselReference
Power74.6 kWReference
Torque433.9 NmReference
Torque RPM1650Reference
Transmission
16-speed two-speed power shiftReference
Typetwo-speed power shiftReference
Gears16 forward and 8 reverseReference
Clutch350mm dry discReference
Oil capacity46.0 LReference
Four gears (1-4) in two ranges (low/high), plus reverse range, with two-speed hydraulic power shift.Reference
PTO & Hydraulics
PTO (claimed)47.7 kWReference
Hydraulic system46.0 LReference
Capacity46.0 LReference
Pressure160.0 barReference
Pump flow40.9 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift4125 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@1890Reference
Engine RPM1000@1920Reference
Front PTO Type1000Reference
Capacities
Fuel90.1 LReference
Dimensions
Wheelbase238 cmReference
Weight4419 kgReference
Front tire12.4-24Reference
Rear tire18.4-34Reference
Ag front12.4-24Reference
Ag rear18.4-34Reference
Length416 cmReference
Width197 cmReference
Height (cab)262 cmReference
Ballasted weight5100 kgReference
Ground clearance38 cmReference
Front tread151/161/170/181 cmReference
Rear tread150/157/165/172/180/187 cmReference
Electrical
Charging systemalternatorReference
Charging amps55Reference
Charging volts12Reference
Batteries2Reference
Battery volts6Reference
Battery AH190Reference
Speeds
With 18.4-34 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
