Tractor · 1991Unverified

Ursus 932

Name: Ursus 932
Brand: Ursus

Ursus 932 — 30 Series · 68 hp. Reference specifications; pending source verification.

The Ursus 932 is a tractor with an engine rating of approximately 68 hp, a mid-range figure for its class. Manufactured between 1991 and 2003, this model features a 4-cylinder diesel liquid-cooled engine, combined with four-wheel drive and a powershift transmission. The tractor has a listed operating weight of 4300 kg and is suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

68 hp

Weight

4300 kg

Catalogue coverage

Variants represented

Richest spec table

69 rows

Recorded power

68 hp

Recorded weight

4300 kg

Transmissions

16-speed two-speed power shift

Production years

1991-2003

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerUrsusReference

Built in Warsaw, PolandReference

Two-wheel driveReference

Differential lockmechanical rearReference

Power steeringReference

Dry disc brakesReference

Cab standard with heat.Reference

Variants

9322WDReference

9344WDReference

Engine

Zetor 4.6L 4-cyl dieselReference

Engine58.8 kWReference

Zetor Z 8401.12Reference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement4.6 LReference

Bore/Stroke110 x 120 mmReference

Power58.8 kWReference

Fuel systemdirect injectionReference

Air cleaneroil bathReference

Compression17:1Reference

Rated RPM2200Reference

Torque277.6 NmReference

Torque RPM1600Reference

StarterelectricReference

Starter volts24Reference

Starter power4.8 kWReference

Oil capacity10.0 LReference

Coolant capacity23.0 LReference

Transmission

16-speed two-speed power shiftReference

Typetwo-speed power shiftReference

Gears16 forward and 8 reverseReference

Clutch350mm hydraulic dry discReference

Oil capacity46.0 LReference

Four gears (1-4) in two ranges (I/II) plus reverse range (R) with two-speed power shift.Reference

PTO & Hydraulics

PTO (claimed)50.8 kWReference

Hydraulic system46.0 LReference

Capacity46.0 LReference

Pump flow40.9 lpmReference

Rear TypeIIReference

Controlposition and draft controlReference

Rear lift4125 kgReference

Rear PTOindependentReference

ClutchhydraulicReference

Rear PTO Type540/1000 (1.375)Reference

Engine RPM540@1890Reference

Engine RPM1000@1920Reference

Capacities

Fuel90.1 LReference

Fuel129.8 LReference

Dimensions

Wheelbase238 cmReference

Weight4300 kgReference

Front tire7.50-20Reference

Rear tire18.4-34Reference

Standard tires (ag)Front: 7.50-20. Rear: 18.4-34Reference

Length414 cmReference

Width196 cmReference

Height (cab)293 cmReference

Height (exhaust)297 cmReference

Ballasted weight4890 kgReference

Ground clearance43 cmReference

Front tread135/150/165/180 cmReference

Rear tread150/157/165/172/180/187 cmReference

Electrical

Charging systemalternatorReference

Charging amps55Reference

Charging volts12Reference

Batteries2Reference

Battery volts12Reference

Battery AH135Reference

Speeds

With 18.4-34 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
