Tractor · 1994Unverified
UTB/Universal 1033
UTB/Universal 1033 — 3 Series · 99 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
99 hp
Weight
4399 kg
Hover a source tag to verify
Overview
ManufacturerUTB/UniversalReference
Built in Brasov, RomaniaReference
Four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Cab standard.Reference
Engine
UTB 5.6L 6-cyl dieselReference
Fuel tank130.0 LReference
Fuel tank180.0 LReference
Engine73.8 kWReference
UTB D261.073Reference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement5.6 LReference
Bore/Stroke110 x 115 mmReference
Power73.8 kWReference
Rated RPM2400Reference
Torque369.1 NmReference
Torque RPM1500Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speedReference
Gears16 forward and 4 reverseReference
PTO & Hydraulics
Pump flow40.1 lpmReference
Rear TypeIIReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase255 cmReference
Weight4399 kgReference
Front tire12.4R28Reference
Rear tire16.9R38Reference
Ag front12.4R28Reference
Ag rear16.9R38Reference
Length439 cmReference
Height284 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
