Tractor · 1987Unverified

UTB/Universal 340

Name: UTB/Universal 340
Brand: UTB/Universal

UTB/Universal 340 — Utility tractor · 30 hp. Reference specifications; pending source verification.

The UTB/Universal 340 is a tractor model with a rated power output of 30 hp, categorising it at the lighter end of its class. It was manufactured from 1987 to 1991. The model features a 2-cylinder diesel liquid-cooled engine, combined with a four-wheel drive system and a 9-speed gearbox. Its operating weight is specified as 3508 to 4144 pounds.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

30 hp

Weight

3508 to 4144 pounds

Catalogue coverage

Variants represented

Richest spec table

49 rows

Recorded power

30 hp

Recorded weight

1591 kg

Transmissions

9-speed gear

Production years

1987-1991

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerUTB/UniversalReference

Utility tractorReference

Built in Brasov, RomaniaReference

Two- or four-wheel driveReference

Differential lockmechanical rearReference

Open operator station.Reference

Variants

340DTC4WDReference

Engine

UTB 1.8L 2-cyl dieselReference

Fuel tank54.1 LReference

Engine25.4 kWReference

UTBReference

dieselReference

2-cylinderReference

liquid-cooledReference

Displacement1.8 LReference

Bore/Stroke102 x 110 mmReference

Power25.4 kWReference

Rated RPM2400Reference

Starter volts12Reference

Transmission

9-speed gearReference

TypegearReference

Gears9 forward and 3 reverseReference

Clutchdry discReference

Three gears, plus reverse, in three ranges.Reference

PTO & Hydraulics

PTO (claimed)22.4 kWReference

Typeopen centerReference

Rear TypeII/IReference

Rear lift1202 kgReference

Rear PTOliveReference

Rear PTO Type540 (1.375)Reference

Engine RPM540@1967Reference

Dimensions

2WD Wheelbase180 cmReference

4WD Wheelbase172 cmReference

Weight3508 to 4144 poundsReference

Front tire6.00-16Reference

2WD Rear tire14.9-28Reference

2WD Standard tires (ag)Front: 6.00-16. Rear: 14.9-28Reference

4WD Standard tires (ag)Front: 7.50-20. Rear: 14.9-28Reference

2WD Length280 cmReference

4WD Length303 cmReference

2WD Height (steering wheel)149 cmReference

4WD Height (steering wheel)151 cmReference

2WD Weight1591 kgReference

4WD Weight1879 kgReference

2WD Ground clearance46 cmReference

4WD Ground clearance27 cmReference

UTB/Universal 340 attachments

front-end loaderReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
