UTB/Universal 450
UTB/Universal 450 — Utility tractor · 42 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
42 hp
Weight
3850 to 5263 pounds
Hover a source tag to verify
Overview
ManufacturerUTB/UniversalReference
Utility tractorReference
Two- or four-wheel driveReference
Final drivesspur gearReference
Differential lockmechanical rearReference
Power steeringReference
Mechanical band brakesReference
Engine
Uzina 2.3L 3-cyl dieselReference
Fuel tank54.1 LReference
UzinaReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.3 LReference
Bore/Stroke95 x 110 mmReference
Compression17:1Reference
Rated RPM2400Reference
StarterelectricReference
Starter volts12Reference
Oil capacity9.1 LReference
Coolant capacity11.6 LReference
Transmission
8-speed shuttleReference
8-speed partially synchronizedReference
TypeshuttleReference
Gears8 forward and reverseReference
Clutch279.4mm dry discReference
Oil capacity16.7 LReference
Typepartially synchronizedReference
Gears8 forward and 2 reverseReference
PTO & Hydraulics
PTO (claimed)31.2 kWReference
Typeopen centerReference
Pressure147.1 barReference
Pump flow37.9 lpmReference
Rear TypeII/IReference
Rear lift1202 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2160Reference
Dimensions
2WD Wheelbase192 cmReference
4WD Wheelbase198 cmReference
Weight3850 to 5263 poundsReference
Front tire6.50x16Reference
2WD Rear tire14.9x28Reference
2WD Standard tires (ag)Front: 6.50x16. Rear: 14.9x28Reference
4WD Standard tires (ag)Front: 9.50x20. Rear: 14.9x28Reference
Lawn/turf front7.50x16Reference
Lawn/turf rear18.4x16AReference
2WD Length295 cmReference
4WD Length311 cmReference
2WD Weight1746 kgReference
4WD Weight2387 kgReference
2WD Ground clearance46 cmReference
4WD Ground clearance39 cmReference
2WD Front tread127 to 195 cmReference
4WD Front tread140 cmReference
Rear tread119 to 190 cmReference
UTB/Universal 450 Height
2WD Hood137 cmReference
4WD Hood145 cmReference
2WD ROPS229 cmReference
4WD ROPS231 cmReference
Speeds
With 14.9x28 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
