The UTB/Universal 524 is a tractor with a rated output of 52 hp — making it one of the more compact options in its class. Power comes from a 3-cylinder diesel liquid-cooled engine, driving through mechanical front-wheel drive with a 12-speed gearbox. It is aimed at jobs of around up to 200 ac. The available specification table below shows both UK and US units.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
52 hp
Catalogue coverage
Variants represented
2
Richest spec table
27 rows
Recorded power
52 hp
Transmissions
12-speed
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerUTB/UniversalReference
Built in Brasov, RomaniaReference
Drive4x2 2WDReference
Drive4x4 MFWD 4WD optionalReference
Engine
UTB 2.8L 3-cyl dieselReference
Fuel tank64.0 LReference
Engine38.8 kWReference
UTBReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.8 LReference
Bore/Stroke102 x 110 mmReference
Power38.8 kWReference
Rated RPM2400Reference
Starter volts12Reference
Transmission
12-speedReference
Gears12 forward and 3 reverseReference
PTO & Hydraulics
Valves2Reference
Pump flow33.0 lpmReference
Rear TypeIIReference
Rear PTOindependentReference
Rear PTO Type540, 1000Reference
Dimensions
Front tire9.50-24Reference
Rear tire16.9-28Reference
Ag front9.50-24Reference
Ag rear16.9-28Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
