Tractor · 1994Unverified
UTB/Universal 723
UTB/Universal 723 — 3 Series · 67 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
67 hp
Weight
6460 to 7198 pounds
Hover a source tag to verify
Overview
ManufacturerUTB/UniversalReference
Utility tractorReference
Built in Brasov, RomaniaReference
Two- or four-wheel driveReference
Final drivesplanetaryReference
Differential lockmechanical rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Cab standard.Reference
Engine
UTB 3.8L 4-cyl dieselReference
Fuel tank62.1 LReference
Engine53.7 kWReference
UTB D2404.050Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.8 LReference
Bore/Stroke102 x 115 mmReference
Power53.7 kWReference
Air cleaneroil bathReference
Rated RPM2400Reference
Idle RPM600-2550Reference
Torque235.0 NmReference
Torque RPM1400Reference
StarterelectricReference
Starter volts12Reference
Oil capacity100.3 LReference
Coolant capacity14.0 LReference
Transmission
16-speedReference
Gears16 forward and 4 reverseReference
Oil capacity49.2 LReference
PTO & Hydraulics
PTO (claimed)50.0 kWReference
Pressure172.4 barReference
Pump flow40.9 lpmReference
Rear TypeIIReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Engine RPM540@2160Reference
Engine RPM1000@2400Reference
Dimensions
2WD Wheelbase219 cmReference
4WD Wheelbase220 cmReference
Weight6460 to 7198 poundsReference
Front tire7.5-20Reference
2WD Rear tire13.6R-36Reference
2WD Standard tires (ag)Front: 7.5-20. Rear: 13.6R-36Reference
4WD Standard tires (ag)Front: 9.5/8-24. Rear: 16.9R-30Reference
Length359 cmReference
Height (cab)250 cmReference
2WD Weight2930 kgReference
4WD Weight3265 kgReference
2WD Front tread139 to 198 cmReference
4WD Front tread137 to 157 cmReference
Rear tread152 to 228 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Speeds
With 16.9R30 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
