Tractor · 1972Unverified
UTB/Universal S445
UTB/Universal S445 — Agricultural Crawler tractor · 42 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
42 hp
Weight
2540 kg
Hover a source tag to verify
Overview
ManufacturerUTB/UniversalReference
Agricultural Crawler tractorReference
Built in Brasov, RomaniaReference
DrivecrawlerReference
Band brakesReference
Open operator station.Reference
Variants
SV445narrowReference
S445standardReference
SM445wide-trackReference
U445wheeled tractorReference
Engine
UTB 2.3L 3-cyl dieselReference
Fuel tank54.1 LReference
UTBReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.3 LReference
Bore/Stroke95 x 110 mmReference
Fuel systemdirect injectionReference
Compression17:1Reference
Rated RPM2400Reference
Torque151.9 NmReference
Torque RPM1500Reference
StarterelectricReference
Starter volts12Reference
Starter power3.0 kWReference
Transmission
6-speed constant meshReference
Typeconstant meshReference
Gears6 forward and 2 reverseReference
Clutch254mm dry discsReference
PTO & Hydraulics
PTO (claimed)31.3 kWReference
Typeopen centerReference
Pressure170.7 barReference
Pump flow22.0 lpmReference
Rear TypeII/IReference
Rear lift1202 kgReference
Rear PTO Type540Reference
Engine RPM540@1970Reference
Dimensions
Wheelbase131 cmReference
Weight2540 kgReference
9.8-inch tracksReference
Length290 cmReference
UTB/Universal S445 attachments
front-end loaderReference
Electrical
Charging systemalternatorReference
Battery volts12Reference
UTB/Universal S445 Tracks
SV445 width24 cmReference
S445 width30 cmReference
SM445 width36 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
