Tractor · 1973Unverified
UTB/Universal U-650M
UTB/Universal U-650M — Utility tractor · 65 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
65 hp
Weight
3380 kg
Hover a source tag to verify
Overview
ManufacturerUTB/UniversalReference
Utility tractorReference
Built in Brasov, RomaniaReference
Two-wheel driveReference
Final drivesspur gearReference
Differential lockmechanical rearReference
SteeringpowerReference
Dry disc brakesReference
Open operator station. Cab optional.Reference
Variants
U-650M2WDReference
U-651M4WDReference
Engine
UTB 4.8L 4-cyl dieselReference
Engine48.5 kWReference
UTB D-110Reference
dieselReference
4-cylinderReference
liquid-cooled inlineReference
Displacement4.8 LReference
Bore/Stroke108 x 130 mmReference
Power48.5 kWReference
Fuel systemdirect injectionReference
Compression17:1Reference
Rated RPM1800Reference
Torque289.1 NmReference
Torque RPM1250Reference
Firing order1-3-4-2Reference
StarterelectricReference
Starter volts12Reference
Transmission
10-speed gearReference
TypegearReference
Gears10 forward and 2 reverseReference
PTO & Hydraulics
Typeopen centerReference
Pressure118.0 barReference
Pump flow40.1 lpmReference
Rear TypeIIReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase243 cmReference
Weight3380 kgReference
Front tire6.50-20Reference
Rear tire14-38Reference
Ag front6.50-20Reference
Ag rear14-38Reference
Length397 cmReference
Width185 cmReference
Height (steering wheel)189 cmReference
Height (cab)262 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps36Reference
Charging volts12Reference
Battery volts12Reference
Battery AH53Reference
Speeds
With 14.00-38 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
