Tractor · 1973Unverified
Valmet 1102
Valmet 1102 — 02 Series · 115 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
115 hp
Weight
8598 to 10340 pounds
Hover a source tag to verify
Overview
ManufacturerValmetReference
Row-Crop tractorReference
Two- or four-wheel driveReference
Power steeringReference
Variants
11028-speedReference
110316-speedReference
Engine
Valmet 4.2L 4-cyl dieselReference
Fuel tank90.0 LReference
Engine85.8 kWReference
Valmet 411 BSReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.2 LReference
Bore/Stroke108 x 114 mmReference
Power85.8 kWReference
Rated RPM2300Reference
Torque352.0 NmReference
Torque RPM1500Reference
Starter volts12Reference
Transmission
8-speedReference
16-speedReference
Gears8 forward and 2 reverseReference
Four gears (1-4) plus reverse (R) in two ranges (low/high).Reference
TransmissionHi-TracReference
Gears16 forward and 4 reverseReference
PTO & Hydraulics
Pump flow36.0 lpmReference
Rear lift3000 kgReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase230 cmReference
Weight8598 to 10340 poundsReference
Front tire9.00-20Reference
Rear tire18.4-34Reference
Ag front9.00-20Reference
Ag front14.9-24 (4WD)Reference
Ag rear18.4-34Reference
Length417 cmReference
Height270 cmReference
2WD Weight3900 kgReference
4WD Weight4690 kgReference
Valmet 1102 attachments
front-end loaderReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
