Tractor · 1993Unverified

Valmet 565

Name: Valmet 565
Brand: Valmet

Valmet 565 — 65 Series · 75 hp. Reference specifications; pending source verification.

The Valmet 565 is a tractor model with a rated power output of 75 hp, a mid-range figure for its class. Manufactured from 1993 to 1997, this model is equipped with a 3-cylinder turbocharged diesel liquid-cooled engine and features four-wheel drive with an 8-speed gearbox. Its operating weight ranges from 6217 to 6834 pounds. It is suitable for operations covering areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

75 hp

Weight

6217 to 6834 pounds

Catalogue coverage

Variants represented

Richest spec table

55 rows

Recorded power

75 hp

Recorded weight

2820 kg

Transmissions

8-speed synchromesh

Production years

1993-1997

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerValmetReference

Utility tractorReference

Two- or four-wheel driveReference

Power steeringReference

Wet disc brakesReference

Engine

Valmet 3.3L 3-cyl dieselReference

Fuel tank73.1 LReference

Engine55.9 kWReference

Valmet 320 DSReference

turbocharged dieselReference

3-cylinderReference

liquid-cooledReference

Displacement3.3 LReference

Bore/Stroke108 x 120 mmReference

Power55.9 kWReference

Compression16.5:1Reference

Rated RPM2350Reference

Starter volts12Reference

Transmission

8-speed synchromeshReference

12-speed creeperReference

TypesynchromeshReference

Gears8 forward and 4 reverseReference

Four gears (1-4) in two ranges (low/high) plus reverse range.Reference

TypecreeperReference

Gears12 forward and 8 reverseReference

Creeper option adds an additional four speeds forward and reverse.Reference

PTO & Hydraulics

Pump flow39.0 lpmReference

Rear lift2500 kgReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Engine RPM540@1890Reference

Dimensions

2WD Wheelbase211 cmReference

4WD Wheelbase225 cmReference

Weight6217 to 6834 poundsReference

Front tire10.00-16Reference

2WD Rear tire16.9R30Reference

2WD Standard tires (ag)Front: 10.00-16. Rear: 16.9R30Reference

4WD Standard tires (ag)Front: 12.4R24. Rear: 16.9R34Reference

2WD Length371 cmReference

4WD Length387 cmReference

2WD Width202 cmReference

4WD Width203 cmReference

2WD Weight2820 kgReference

4WD Weight3099 kgReference

2WD Clearance (front axle)50 cmReference

4WD Clearance (front axle)43 cmReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps45Reference

Battery volts12Reference

Valmet 565 Height

2WD Cab248 cmReference

4WD Cab255 cmReference

2WD Exhaust260 cmReference

4WD Exhaust263 cmReference

Speeds

With 16.9R30 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
