Tractor · 1991Unverified
Valmet 6600
Valmet 6600 — Mezzo Series · 103 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
103 hp
Weight
4399 kg
Hover a source tag to verify
Overview
ManufacturerValmetReference
Row-Crop tractorReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Cab standard with optional air-conditioning.Reference
Engine
SisuDiesel 4.4L 4-cyl dieselReference
Fuel tank165.0 LReference
Engine77.0 kWReference
SisuDiesel 420 DSReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.4 LReference
Bore/Stroke108 x 120 mmReference
Power77.0 kWReference
Compression16.5:1Reference
Rated RPM2225Reference
Torque405.0 NmReference
Torque RPM1550Reference
StarterelectricReference
Starter volts12Reference
Transmission
24-speed two-speed power shiftReference
36-speed three-speed power shiftReference
Typetwo-speed power shiftReference
Gears24 forward and reverseReference
TransmissionDelta PowershiftReference
Typethree-speed power shiftReference
Gears36 forward and reverseReference
Four gears in three ranges with three-speed power shift and shuttle.Reference
PTO & Hydraulics
Pump flow70.0 lpmReference
Rear TypeIIReference
Rear lift5499 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Engine RPM540@1874Reference
Engine RPM1000@2080Reference
Dimensions
Wheelbase232 cmReference
Weight4399 kgReference
Front tire13.6R24Reference
Rear tire16.9R38Reference
Ag front13.6R24Reference
Ag rear16.9R38Reference
Length442 cmReference
Height (cab)275 cmReference
Height (exhaust)281 cmReference
Clearance (front axle)51 cmReference
Clearance (rear axle)48 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Battery AH150Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
